battery type

Li-ion battery

LiFePO4

Cell numbers

2~16

2~18

overcharge detection voltage

4.325V (4.295V—4.355V)

3.90V (3.87V—3.93V)

Overcharge release voltage

4.075V (4.045V—4.105V)

3.80V (3.77V—3.83V)

balance Activation voltage

4.2V (4.17V—4.23V)

3.60V(3.57V—3.63V)

balance release voltage

4.2V (4.17V—4.23V)

3.60V(3.57V—3.63V)

Over-discharge detection voltage

2. 50V (2.45V—2.55V)

2. 00V (1.95V—2.05V)

Over-discharge release voltage

2.90V (2.85V—2.95V)

2.30V (2.25V—2.35V)

max. continuous discharge current

2~100Aadjustable

2~100Aadjustable

Over current detection current

5~150Aadjustable

5~150Aadjustable

current consumption in over-discharge or load removed

less than 20uA

less than 20uA
